Drill Bits Grinding Machine: Industrial-Grade Features, Technical Specs & Competitive Advantages
1. Core Features (Industrial-Grade Design)
- Wide Compatibility: Grinds HSS, carbide, cobalt, titanium-coated, and masonry drill bits; diameter range 3–30mm (1/8″–1 3/16″) for industrial and precision drilling needs.
- Precision Angle Control: Adjustable point angles (118°, 120°, 135°, 140°) with 0.1° fine-tuning; supports split point, parabolic, and twist drill geometries for different materials (steel, aluminum, concrete).
- Semi-Automatic Operation: CNC-assisted positioning (optional) + manual feed; digital display for angle/grinding time settings; reduces human error and boosts batch consistency.
- Heavy-Duty Stability: Cast iron frame + vibration-damping base; minimizes runout during high-speed grinding; suitable for 24/7 continuous workshop use.
- Durable Grinding System: CBN (cubic boron nitride) or diamond grinding wheel (Φ150/200mm); wear-resistant, heat-dissipating, and maintains sharpness for 10,000+ grinding cycles.
- Comprehensive Safety: Emergency stop button, dust collection port (compatible with industrial vacuums), and protective cover; meets OSHA/CE safety standards.
2. Technical Specifications
| Parameter | Specification |
|---|---|
| Voltage | 110V/220V (single-phase) / 380V (three-phase, optional) |
| Power | 1.5KW–3.0KW (adjustable based on model) |
| No-Load Speed | 2800–4500 RPM |
| Applicable Drill Diameter | 3–30mm (1/8″–1 3/16″) |
| Point Angle Range | 118°–140° (0.1° fine adjustment) |
| Grinding Wheel | CBN/diamond-plated, Φ150/200mm × 15/20mm |
| Runout Accuracy | ≤0.005mm |
| Angle Error | ±0.1° |
| Grinding Cycle Time | 20–60 seconds/drill (varies by diameter) |
| Automation Level | Manual/semi-automatic/CNC (optional) |
| Net Weight | 45–80kg (model-dependent) |
| Dimensions (L×W×H) | 550×400×600mm – 700×500×750mm |
| Certification | CE, ISO 9001, RoHS, OSHA |
| Dust Collection | Φ50mm port (compatible with industrial vacuums) |
3. Competitive Advantages
- Industrial Efficiency: Semi-automatic/CNC options enable batch grinding (300+ drills/hour); cuts downtime for tool maintenance in manufacturing plants.
- Cost Reduction: Extends drill lifespan by 4–6 times (especially high-cost carbide drills); reduces tool replacement costs by 60%+ for heavy-use industries.
- Precision for Critical Applications: 0.005mm runout accuracy meets aerospace, automotive, and mold-making requirements (drilling precision ±0.01mm).
- Low Total Cost of Ownership: Durable CBN/diamond wheels (no frequent replacement); energy-efficient motor (saves 20% power vs. conventional grinders); 2-year warranty for core components.
- Customization Flexibility: Supports tailored solutions (e.g., larger diameter ranges, special angle geometries, full CNC integration) for industry-specific needs.
- Global Trade Readiness: Multi-voltage design, export-standard packaging (shockproof, moisture-proof), and multi-language technical manuals (English, German, French, Spanish, Chinese).
4. Application Scenarios
- Heavy-industry workshops (steel/metal fabrication, construction machinery).
- Precision manufacturing (aerospace parts, automotive components, mold making).
- Tool repair centers and drill bit manufacturers.
- Construction and infrastructure projects (masonry drill maintenance).
